The six lanes are supported over a reversible 32-pin superMHL connector, while four lanes are supported over USB-C Alternate Mode (only a single lane is supported over micro-USB/HDMI). The HDMI alternate mode lets a user connect the reversible USB-C connector with the HDMI source devices (mobile, tablet, laptop). 165 MHz was the maximum TMDS character rate allowed in version 1.2a of the HDMI Specification and earlier. In version 1.3, the maximum allowed speed was increased to 340 MHz, and in version 2.0 it was increased to 600 MHz. HDMI 2.0 increases the maximum bandwidth to 18.0 Gbit/s. To make HDMI more suitable for use on PC devices, version 1.2 also removed the requirement that only explicitly supported formats be used. Previous HDMI versions use three data channels (each operating at up to 6.0 Gbit/s in HDMI 2.0, or up to 3.4 Gbit/s in HDMI 1.4), with an additional channel for the TMDS clock signal, which runs at a fraction of the data channel speed (one tenth the speed, or up to 340 MHz, for signaling rates up to 3.4 Gbit/s; one fortieth the speed, or up to 150 MHz, for signaling rates between 3.4 and 6.0 Gbit/s). Both HDMI and DVI use TMDS to send 10-bit characters that are encoded using 8b/10b encoding that differs from the original IBM form for the video data period and 2b/10b encoding for the control period.

The TMDS character rate is the number of 10-bit TMDS characters per second transmitted across one HDMI data channel. HDMI Ethernet Channel technology consolidates video, audio, and data streams into a single HDMI cable, and the HEC feature enables IP-based applications over HDMI and provides a bidirectional Ethernet communication at 100 Mbit/s. HDMI 1.0 requires support for RGB video, with optional support for Y′CBCR 4:4:4 and 4:2:2 (mandatory if the device has support for Y′CBCR on other interfaces). Transition-minimized differential signaling (TMDS) on HDMI interleaves video, audio and auxiliary data using three different packet types, called the video data period, the data island period and the control period. It defines two connectors called type A and type B, with pinouts based on the Single-Link DVI-D and Dual-Link DVI-D connectors respectively, though the type B connector was never used in any commercial products. In conjunction with the HDMI 2.1 specification, a third category of cable was announced on January 4, 2017, called "48G".

In December 2010, it was announced that several computer vendors and display makers including Intel, AMD, Dell, Lenovo, Samsung, and LG would stop using LVDS (actually, FPD-Link) from 2013 and legacy DVI and VGA connectors from 2015, replacing them with DisplayPort and HDMI. This cable connects to video display/sink devices using any of the native HDMI connectors. HDCP DDC signals must be multiplexed with TMDS video signals to comply with HDCP requirements for HDMI extenders based on a single Category 5/Category 6 cable. HDMI can only be used with older analog-only devices (using connections such as SCART, VGA, RCA, etc.) by means of a digital-to-analog converter or AV receiver, as the interface does not carry any analog signals (unlike DVI, where devices with DVI-I ports accept or provide either digital or analog signals). The DisplayPort features an adapter detection mechanism enabling dual-mode operation and the transmission of TMDS signals allowing the conversion to DVI and HDMI 1.2/1.4/2.0 signals using a passive adapter. Some of the transmitted bits are used for encoding purposes rather than representing data, so the rate at which video data can be transmitted across the HDMI interface is only a portion of the total bit rate.

Each packet contains four subpackets, and each subpacket is 64 bits in size, including 8 bits of BCH ECC parity data, allowing for each packet to carry up to 224 bits of audio data. Each data island period can contain up to 18 packets. Uncompressed LPCM audio, however, does not require a Protected Audio Path, and software programs such as PowerDVD and WinDVD can decode Dolby TrueHD and DTS-HD MA and output it as LPCM. In comparison, the Protected Audio Path was required only if a lossless audio bitstream (such as Dolby TrueHD or DTS-HD MA) was output. The ATI Radeon HD 5870 released in September 2009 is the first video card that allows bitstream output over HDMI for Dolby TrueHD and DTS-HD Master Audio. It also optionally allows output of Dolby TrueHD and DTS-HD Master Audio streams for external decoding by AV receivers. CEC also allows for individual CEC-enabled devices to command and control each other without user intervention.
